| Utility | Power supply | 3-phase AC200/220V 50/60Hz |
| Compression air | 0.5MPa, 1500L/min (ANR) or more |
| Applicable module PKG | Power Devices, ECU etc. |
| Work placeable area | (W) Max. 110 mm x (L) Max. 200 mm x 4 areas/press |
| Clamping force | 196~1,667kN (170tf) |
| Transfer force | 4.9~98kN (10tf) |
Machine size
(excluding the signal pole) | 1 press | (W) 3,950 x (D) 3,110 x (H) 2,300 mm |
| 3 press | (W) 5,750 x (D) 3,110 x (H) 2,300 mm |
Machine weight
(including the molds) | 1 press | Approx. 7,000kg |
| 3 press | Approx. 15,000kg |
Applicable
compound | Form | Mini tablet |
| Dia. | 13~20 mm |
| Loading method | In-line Type | Pick & place from conveyer (provided by customer) |
| Stand-alone Type | Magazine loading |
| Off-loading method | In-line Type | Pick & place to conveyer (provided by customer) |
| Stand-alone Type | Magazine off-loading |
