| ITEM | DETAILS |
|---|
| Target workpiece | SMD crystal, 2016 |
|---|
| Target workpiece size | 3.2×2.5～1.0×0.8（㎜） |
|---|
| Inspection items | Frequency and resistance |
|---|
| Inspection temperature range | ー40°C to +120°C (5 points: Temperature range consulted) |
|---|
| Work supply | Parts feeder |
|---|
| Workpiece transfer | Dedicated carrier (64 pcs/tray) |
|---|
| Work storage | Storage box |
|---|
| Cycle time | Approx. 0.5 sec./piece (It may elongate depending on the measurement conditions.) |
|---|
| External Dimensions | Standard-specification: W2450×D1100×H1700 mm (excluding protrusions such as measuring instruments and patlites) |
|---|
*Configuration and specifications of this machine are subject to partial modification without prior notice.
